Additional Features:
- 50 MHz Tracking Generator
- Spectrum Analyzer
- Duplex
- Terminated RF Wattmeter
- Programmable Test Memory
- Relative Signal Strength Meter
- RF Scan/RF Counter Function
- Signaling Simulator: Encoder and Decoder
- General Purpose & Modulation Oscilloscope
- AM, FM Signal Generator
- Off-the-Air Sensitive Receiver
- Graphic Screen Print, and Self-Calibration
- RS-232/Serial Printer Interface
- Cable Fault
In TDMA mode, the R-2660A provides the following special measurement features:
- Average power meter
- Frequency error meter
- SQE (Signal Quality Estimate)
- BER (Bit Error Rate)
The Motorola R-2660A is a Communications System Analyzer. As an addition to Motorola’s test equipment family, the R-2660A is designed to provide fully compatible testing of iDEN radio systems. Whether you’re testing subscriber units or site equipment, the R-2660A offers the unique capability to test iDEN systems under actual TDMA operating conditions in either 6:1 or 3:1 format. Comprehensive diagnostic capabilities are provided to facilitate fault isolation and repair.
In addition, the unit also provides dedicated screen displays for convenient observation or printout; innovative use of soft keys and windowing; fast reacting auto ranging scales with both analog and digital readouts; and signaling encode and decode functions – all built into a versatile, rugged, and compact test unit designed specifically to meet the tough demands of the field service environment.
